| Converter Transformers Approved For Use With ANALOG DEVICES High-Speed Transceivers |
Compatibility with ADM2485 speeds implementation of isolated RS-485 and RS-422 interfaces
- Transformers recommended by Analog Devices for use with ADM2485 transceiver
- Low profile device offers 2.5kVrms isolation and industrial temperature operation
- Accurately controlled turns ratio for consistent performance
- Toroidal construction maximises efficiency and reduces EMI
|
October 2007, Mansfield, Massachusetts
Murata Power Solutions has announced a new series
of transformers that simplify implementation of isolated RS-485 and
RS-422 interfaces based on Analog Devices chipsets by eliminating
the need to select, compare and test alternative solutions.
Each device in the new 782485 converter transformer series has been specifically designed for use with the Analog Devices ADM2485 high speed, isolated differential bus RS-485 transceiver. Fully approved by Analog Devices, the transformers are also recommended in the company's ADM2485 datasheets and reference design documentation.
Available with nominal input voltage variants of 3.3V and 5.0V, the 782485 transformers offer 2.5kVrms isolation and deliver a nominal output voltage of 6.0V. Maximum output current is 200mA. Accurately controlled turns ratios ensure consistent performance, whilst the toroidal construction provides high efficiency and minimises EMI.
Incorporating an internal transformer driver, the Analog Devices ADM2485 is deployed in isolated RS-485 and RS-422 interfaces as well as PROFIBUS® networks, industrial field networks and multipoint data transmission systems. Combining the device with a Murata Power Solutions 782485 transformer, an LDO regulator and a small number of discrete components allows designers to quickly implement a fully isolated 5V power supply.
