| Imaging Signal Processor Provides High-Performance Functionality, Simple Interface, for a Complete Solution |
- 16-Bit resolution, 3MPPS throughput rate
- Industry leading SNR of 85dB at 3MHz
- Fully integrated low power design in small 40-pin TDIP package
|
October 2006, Mansfield, Massachusetts
Murata Power Solutions
has introduced the first Imaging Signal Processor to combine true 16-Bit resolution with 3 Megapixels / second (MPPS) performance. The ADCDS-1603 provides an easy-to-interface, functionally complete, low-cost solution for electronic imaging applications that use Charge Coupled Devices (CCDs) as their photo-detectors.
Typical applications for the high-performance ADCDS-1603 can be found in Digital Still Cameras, Digital Video Camcorders, portable CCD image devices, plus a wide range of medical and industrial imaging products.
The ADCDS-1603 has a class-leading signal-to-noise-ratio of 85dB at 3MHz with no latency delay. The small, fully integrated 40-pin TDIP package incorporates a user configurable input amplifier, a correlated double sampler (CDS), and a 16-Bit sampling analog-to-digital converter (ADC). Further features of the user-friendly design include edge triggering, gain adjust, offset adjust, a precision +2.0V reference and a programmable analog input bandwidth function. Overall power consumption is just 500mW typical.
Central to the ADCDS-1603's high performance is a unique high-speed, high-accuracy, CDS circuit that eliminates the effects of residual charge, charge injection and kT/C noise on the output capacitor of the CCD. This produces a 'valid video' output signal that the ADCDS-1603 digitizes using its integral high-speed, low-noise sampling ADC.
Two variants of Murata Power Solutions new Imaging Signal Processor are
available: The ADCDS-1603 is designed for commercial applications
and has an operating temperature range of 0ēC to +70ēC, while the
ADCDS-1603EX has an operating temperature range of -55ēC to +125ēC
making it suitable for military and more demanding commercial applications.
Higher volume prices under $125.00. Delivery from stock is 4 to 6 weeks.
